Pump D - Mechanical Diaphragm Metering Pump


Mechanical Diaphragm Metering Pump

Brochure -SR Type D Pump
Mechanical Diaphragm Dosing Pump

"D" type mechanical diaphragm metering pumps are suitable for use when the liquid contains small suspended solids and when low to medium pressures are required. The gearbox is a standard worm drive reduction system and is available with either a NEMA 56C motor flange (with or without motor) and also available with an IEC B14 electric motor that meets UNEL-MEC specification. The mechanism for variation of the stroke length is a positive stroke spring return operated by an eccentric. Stroke adjustment can be done manually, electrically (4-20mA; Profibus) and pneumatically. Different multiple head units are available on request.The entire “D” series can be ATEX certified.

Type

Max. Capacities Max. Pressure
D 050U 1.27 to 13 GPH 145 PSI
D 100U 14.2 to   99 GPH 72 PSI
D 101U 28.5 to 129 GPH 116 PSI
D 121U 102 to  181 GPH 43 PSI
    Higher Pressures Available

Materials of Construction 11 12 13 23
Pump Head S.S.316 PP/FRV PVC PVDF
Diaphragm PTFE/NBR PTFE/NBR PTFE/NBR PTFE/NBR
Valve seat S.S.316 PP PVC PVDF
Valve ball S.S.316 PYREX PYREX PYREX
Note: Others upon requests.

Return to Last Page



Type B- Hydraulic Diaphragm Metering Pump


Hydraulic Diaphragm Metering Pump

Brochure - SR Type B
Type B- Hydraulic Diaphragm Metering Pump

"B" type hydraulic diaphragm metering pumps are suitable for use when the liquid contains small suspended solids, when higher pressures are required and when piston seepage is not acceptable. The gearbox is a standard worm drive reduction system and is available with either a NEMA 56C motor flange (with or without motor) and also available with an IEC B14 electric motor that meets UNEL-MEC specifications. The mechanism for variation of the stroke length is a positive stroke spring return operated by an eccentric. Stroke adjustment can be done manually, electrically (4-20mA; Profibus) and pneumatically. Different multiple head units are available on request. The entire series can be ATEX certified.

Type Max Capacities Max Pressure
B 125U .47 to 28.5 GPH 290 PSI
B 175U .82 to 110 GPH 290 PSI
B 250U 33.2 to 290 GPH 159 PSI
    Higher Pressures Available

Materials of Construction 41 43 29
Pump head S.S.316 PVC PP
Diaphragm PTFE PTFE PTFE
Piston S.S.420 S.S.420 S.S.420
Piston gasket AU/NBR AU/NBR AU/NBR
Oil chamber All. All. All.
Valve seat S.S.316 PVC PP
Valve ball S.S.316 PYREX PYREX
Note: Others upon requests.

Return to Last Page


Pump Type  BR - Hydraulic diaphragm dosing pump with internal safety valve


Hydraulic Diaphragm Dosing Pump with Internal Safety Valve

Brochure - SR Type BR
Pump Type  BR - Hydraulic diaphragm dosing pump with internal safety valve

"BR" type hydraulic diaphragm metering pumps are suitable for use when the liquid contains small suspended solids and when piston seepage is not acceptable. A pressure relief valve is included to guarantee diaphragm security when an over pressure situation occurs. The gear box is a standard worm drive reduction system and is available with either a NEMA 56C motor flange (with or without motor) and also available with an IEC B14 electric motor that meets UNEL-MEC specifications. The mechanism for variation of the stroke length is a positive stroke spring return operated by an eccentric. Stroke adjustment can be done manually, electrically (4-20mA; Profibus) and pneumatically. Different multiple head units are available on request. The series can be ATEX certified.

Type Max Capacities Max Pressure
BR 125U .47 to 28.5 GPH 195 PSI
BR 175U .82 to 110 GPH 203 PSI
BR 250U 33.2 to 290 GPH 104 PSI
    Higher Pressures Available

Materials of Construction 41 43 29
Pump head S.S.316 PVC PP
Diaphragm PTFE PTFE PTFE
Piston S.S.420 S.S.420 S.S.420
Piston gasket AU/NBR AU/NBR AU/NBR
Oil chamber All. All. All.
Valve seat S.S.316 PVC PP
Valve ball S.S.316 PYREX PYREX
Note: Others upon requests.

Return to Last Page


Pump SD - Hydraulic diaphragm dosing pump with internal safety valve


Sandwich Hydraulic Diaphragm

Brochure - SR Type SD
Type SD Pump - Sandwich Hydraulic Diaphragm

"SD" type sandwich hydraulic diaphragm metering pumps are suitable for use when the liquid contains small suspended solids and when piston seepage is not acceptable. A pressure relief valve is included to guarantee diaphragm security when an over pressure situation occurs. It also includes a sandwich (double) diaphragm system with rupture detection. The gearbox is a standard worm drive reduction system and is available with either a NEMA 56C motor flange (with or without motor) and also available with an IEC B14 electric motor that meets UNEL-MEC specifications. The mechanism for variation of the stroke length is a positive stroke spring return operated by an eccentric. Stroke adjustment can be done manually, electrically (4-20mA; Profibus) and pneumatically. Different multiple head units are available on request. The entire series can be ATEX certified.

Type Max Capacities Max Pressure
SD 125U .47 to 28.5 GPH 195 PSI
SD 175U .82 to 105 GPH 203 PSI
SD 250U 33 to 290 GPH 104 PSI
    Higher Pressures Available
SD 125U High Pressure .47 to 28.5 GPH 580 PSI
SD 175U High Pressure .82 to 105 GPH 580 PSI
SD 250U High Pressure 33 to 290 GPH 300 PSI

Materials of Construction 05 03 11
Pump head S.S.316 PVC PP
Diaphragm PTFE PTFE PTFE
Piston S.S.420 S.S.420 S.S.420
Piston gasket AU/NBR AU/NBR AU/NBR
Oil chamber All. All. All.
Valve seat S.S.316 PVC PP
Valve ball S.S.316 PYREX PYREX
Note: Others upon requests.

Return to Last Page


Type SD-I - SD-I Sandwich Hydraulic Diaphragm


Sandwich Hydraulic Diaphragm

Brochure - PDP Type SD-I
Type SD-I - SD-I Sandwich Hydraulic Diaphragm

"SD" type sandwich hydraulic diaphragm metering pumps are suitable for use when the liquid contains small suspended solids and when piston seepage is not acceptable. A pressure relief valve is included to guarantee diaphragm security when an over pressure situation occurs. The sandwich (double) diaphragm system includes rupture detection. The PDP series is manufactured according to API standard 675. Stroke adjustment can be done manually, electrically (4-20mA; Profibus) and pneumatically. Accuracy is better than 1% from 10 to 100%. Different multiple head units are available on request. A wide range of liquid end materials are available such as Hastelloy, PTFE, & Alloy 20. The entire series can be ATEX certified.

Type Max Capacities Max Pressure
SD I 175 .55 to 103 GPH 162 PSI*
SD I 250 .63 to 494 GPH 162 PSI
SD I 350 21.8 to 1,112 GPH   162 PSI
AP SD I 175 .55 to 60 GPH 464 PSI*
AP SD I 250 .63 to 192 GPH 928 PSI
AP SD I 350 21.8 to 403 GPH   649 PSI
    Higher Pressures Available
* New item - contact for details.
Materials of Construction 05 03 11
Pump head S.S.316 PVC PP
Diaphragm PTFE PTFE PTFE
Piston S.S.420 S.S.420 S.S.420
Piston gasket AU/NBR AU/NBR AU/NBR
Oil chamber All. All. All.
Valve seat S.S.316 PVC PP
Valve ball S.S.316 PYREX PYREX
Note: Others upon requests.

Return to Last Page



Type A1 - Piston Metering Pump


Piston Metering Pump

Brochure - SR Type A
Type A1 - Piston Metering Pump

"A" type piston metering pumps are suitable for use when the liquid is a non-abrasive solution and when higher pressures are required. The gearbox is a standard worm drive reduction system and is available with either a NEMA 56C motor flange (with or without motor) and also available with an IEC B14 electric motor that meets UNEL-MEC specifications. The mechanism for variation of the stroke length is a positive stroke spring return operated by an eccentric. Stroke adjustment can be done manually, electrically (4-20 mA; Profibus) and pneumatically. Different multiple head units (duplex/triplex/quadruplex and more) are available on request. The entire series can be ATEX certified.

Type Max. Capacities Max. Pressure
A 125U .26 to 41   GPH 290 PSI
A 175U .41 to 103 GPH 290 PSI
A 250U 13 to 283 GPH 290 PSI
A 350U 230 to 395 GPH 58 PSI

AP A 125U .41 to 11.7 GPH 3625 PSI
AP A 175U .35 to 4 GPH 3625 PSI
AP A 1 250U 1 to 7,5 GPH 3625 PSI
    Higher Pressures Available

Materials of Construction 11 13 17 20 32 06
Pump head S.S.316 PVC S.S.316 PVC S.S.316 PP
Piston S.S.316 Ceramic Ceramic S.S.316 S.S.420 Ceramic
Piston gasket NBR FPM FPM NBR AU FPM
Valve seats S.S.316 PVC S.S.316 PVC S.S.316 PP
Valve ball S.S.316 PYREX S.S.316 PYREX S.S.316 PYREX
Note: Others upon requests.

Return to Last Page


Type A1 - Piston Metering Pump


Piston Metering Pump

Brochure - PDP Type A-1
Type A1 - Piston Metering Pump

"A - I " type piston metering pumps are suitable for use when the liquid is a non abrasive solution and when higher pressures are required. The PDP series is manufactured according to the API Standard 675. Stroke adjustment can be done manually, electrically (4-20mA; Profibus) and pneumatically. Accuracy is better than 1% from 10 to 100%. Different multiple head units (duplex/triplex/quadruplex and more) are available on request. A wide range of materials like Hastelloy, Alloy 20, and PTFE are available. The entire series can be ATEX certified..

Type Max. Capacities Max. Pressure
A - I - 175 .25 to 103 GPH 725 PSI*
A - I - 250 .38 to 435  GPH 580 PSI
A - I - 350 16 to1004  GPH 580 PSI
AP - A - I - 175 .41 to 11.7 GPH 3625 PSI*
AP - A- I - 250 .69 to 43 GPH 3625 PSI
AP - A - I - 350 6 to 124 GPH 3625 PSI
    Higher Pressures Available
* New item - contact for details.

Materials of Construction 11 13 17 20 32 06
Pump head S.S.316 PVC S.S.316 PVC S.S.316 PP
Piston S.S.316 Ceramic Ceramic S.S.316 S.S.420 Ceramic
Piston gasket NBR FPM FPM NBR AU FPM
Valve seats S.S.316 PVC S.S.316 PVC S.S.316 PP
Valve ball S.S.316 PYREX S.S.316 PYREX S.S.316 PYREX
Note: Others upon requests.

Return to Last Page
